Embedded PC EN-50155 Certified for Railway use, Xeon, I3,I5,I7 CPU sypport, 6xEthernet, 4x USB, VGA, DVI-D
Call +45 56 66 20 20 for price
Ekskl. moms
CPU support gen.6/7 Intel® Xeon® E3/ 6th & 7th generation Core™ i7/ i5/ i3 processor in LGA1151 socket
Fanless design
4 x 802.3af Gigabit PoE ports by M12 connectors
Support RTC battery service window
2 x mPCIe slots for optional Wi-Fi/ BT/ 3G/ 4G/ GPS modules
1 x M.2 (NGFF) M-Key(2242) socket for storage module
1 x SIM card sockets
Dimensions (W x D x H)225 x 292 x 90 mm
Wide temperature range from -40°C to 70°C
Wide range DC power input (9~36V)
EN-50155 certified
Quantity
Ask a question
close
Specifications
| CPU | i3; i5; i7; Xeon |
|---|---|
| Chipset | Intel® C236 |
| Approval | EN-50155 certified. |
| Chok/Vibration | IEC61373; IEC61373 |
| Dimensioner | 225 x 292 x 90 mm |
| DVI | 1 |
| Ethernet | 6 |
| HDMI | 0 |
| Luftfugtighed | 10 ~ 95% |
| mPCIe | 1 |
| OS SUPPORT | Windows 10 IoT; Windows 7; Windows 8.1; Linux |
| SATA | 3 |
| SIM kort | 2 |
| USB | 4 |
| VGA | 1 |
