7-channel 4-20mA current data logger, speed 20ms to 12 hours, 16bit resolution, 2MB of memory Battery operation, USB
6,610.00 kr
Ekskl. moms
16-bit 4-20mA to-digital converter
With temperature compensation
2 Megabyte memory to log data
USB and RS232, automatic baud rate up to 115.2kbit
Input ranges (4-20mA, version with 0-50mA)
Battery operation - 10 year battery
Add on: Software for configuring, downloading, graphing, analysis and alarm reporting (not included)
Configurable alarm controls / overvoltage control
Measurement speed from 20 milliseconds (1 channel) to 12 hours
Robust aluminum housing
coated printed circuit board for protection against moisture, corrosion
Quantity
Ask a question
close
Specifications
| Alarm | 2 x programmerbare alarmer per kanal |
|---|---|
| Batteri | Op til 10 år |
| Dimensioner | 88 x 64 x 24mm - vægt 200 gram |
| Kanaler | 7 stk. strøm indgange 4 - 20mA |
| Måleområde | 4-20mA, version 2 er 0-50mA |
| Software | Site View til opsætning og visning skal tilkøbes |
Data loggers with 7 channels input, battery-operated, stand-alone high precision to 4-20mA by up to 2 MB flash memory.
Input current signals may be from sensors, transducers, transmitters or other conventional power sources. Its built
temperature channel provides environmental monitoring and temperature compensation.
Its aluminum body makes it ideal for the toughest industrial environments.
Plug Play USB port and versatile user-defined equations simplify the conversion of the unit.
16-bit ADC makes it suitable for science and laboratory purposes where accurate and precise measurements are critical.
