21.5" Medical Premium Windows Touch Panel PC Celeron,I3,I5,I7,16:9, PCAP touch, Medical Certificate
Call +45 56 66 20 20 for price
Ekskl. moms
CPU support Celeron, i3, i5, i7 Gen.8
Max. 32GB RAM
21.5” True-Flat
16:9 Ratio
1920x1080 pixel
PCAP touch USB
Wifi
BT
2 x RJ45
4 x USB3.0
1 x RS232, 1xRS232(5v/12v support)/422/485
1 x HDMI, 1 x DVI-D
Ultra Slim 49.9mm with 3 Pieces Design
Fanless & Front Panel IP65
Simple Installation & Easy Assembly
Industrial Quality & Chic Appearance
Support TPM and Intel vPro (Optional)
Magnetic I/O Port Cover For Easy Maintaining ( Optional)
Extensional Power Button (Optional)
TPM
9~36Vdc
543x334x49.9 mm
OS support: Win10, Win 11, Linux
Quantity
Ask a question
close
Specifications
| CPU | Intel Core i5 Processor: i5-8365UE vPro Intel Core i7 Processor: i7-8665UE vPro (optional) Intel Core i3 Processor: i3-8145UE (optional) Intel Celeron Processor : 4305UE (optional) |
|---|---|
| Farve | Black, Silver, Black / White, Silver, White, need to be specified when ordering |
| Approval | FCC Class B, CE Mark, CB, ICE60601 |
| bluetooth | 1 x Bluetooth |
| Dimensioner | 543 x 334 x 49.9 mm |
| Ethernet | 2x RJ45, Intel I219LM (Phy); Intel I211 (PCIe) |
| Forsyning | support 9-36V DC-in, Power adapter 90W/19V, 3-pin |
| Grafik | Intel UHD |
| Hukommelse | 2 x S.O.DIMM, DDR4 2400MHz, 8GB (Up to 32GB) |
| IP-Tæthed | IP65 on the front |
| Kamera | 2M WebCam (HD webcam, USB interface) |
| Luftfugtighed | Operating 20% - 80% RH non-condensing |
| Lyd | Realtek ALC662VDO-GR |
| M.2 | 1 x PCIex4 M.2 2280 B or SATA I/F (Up to 1TB) |
| Mål og vægt | 7.6-8 kg (net weight) |
| Opløsning | 1920 x 1080 ; 16:9 |
| OS SUPPORT | Windows 10, Windows 11, Linux |
| Porte | 1 x DB9 (RS232), 2 x DB9 (RS232/422/485)-(RS232 support 5V/12V) |
| Skærm | 21.5" LVDS I/F |
| SSD | 1 x SSD 2.5" 7mm Sata max 1TB |
| Touch | True-Flat PCAP touch, USB I/F |
| TPM | yes |
| Udgange | 1xHDMI, 1xDVI-D |
| USB | 4 x USB3.0 |
| VESA standard | Vesa mount 100x100 |
| speaker | 2 x 2W |
| Nits | 350 nits |
Smart Healthcare Solution
Bringing diagnostics, health records to the digital world offers a chance to improve efficiency and satisfaction.
21.5” Medical Grade Touch All In One System Panel PC
Intel® Whiskey Lake i5-8365UE vPro
-Medical Anti-Bacterial Materials
-Medical Power Adapter
-Electrostatic Discharge Protection
-Medical Certificate
