19" i5 ECDIS DNVGL-CG-0339, IACS E10 Marine approved Panel PC, 24VDC
Call +45 56 66 20 20 for price
Ekskl. moms
19" 1280 x 1024 Marine approved Panel PC
Projective multitouch screen PCAP
Marine standard: DNVGL-CG-0339, IEC60945 4th. IACS-E10
Intel Core i5-5200U 2.2GHz
4GB RAM, 128GB SSD (mSATA) Dual ethernet
Supports Win 10 IoT Enterprise (must be purchased separately)
2 x USB 3.0, 1 x USB2.0
1 x RS232 (RS422/485)
2 x RJ45
Option: 8 ch DI/DO (additional purchase)
Option: 4 x NMEA 0183 port (additional purchase)
Supply voltage: 24VDC / 65Watt
DC input: 9 - 36VDC
Dimensions: 429 x 382 x 73 mm
Weight: 7.8 kg
Quantity
Ask a question
close
Specifications
| CPU | Intel Core i5-5200U Broadwell 2.2GHz |
|---|---|
| Farve | 16.7 M colors, 8 bits/color |
| Betragtningsvinkel | 85°/85°/80°/80° (typ.) (Up/Down/Left/Right) |
| Chok/Vibration | Anti-Vibration 0.7g@DNV2.4 (Class A) Anti Shock 15G, 11ms duration |
| Digital I/O | 8 Channel Isolated Digital Input/Output (Optional) |
| Driftstemperatur | -15 to 55 deg.C |
| Ethernet | Dual Ethernet Gb LAN, 2 x RJ45 |
| Hukommelse | 1 x DDR3L-1066 SODIMM (Default 4GB,Max 16GB) |
| Kontrast | 1000:1 (typ.) |
| Luftfugtighed | 5% to 95% (non condensing) |
| Lyd | Buzzer 75 dB~80 dB, 2300 Hz, 1m Speaker 2 x 2W Speaker |
| Pixels | 0.294 (H) x 0.294 (V ) mm |
| Skærm | 19" |
| Strømforbrug | 80W |
| Strømforsyning | 24V DC-in with Isolation (9~36V acceptable), DC Power Signal 1 x 3-Pin Terminal Block (Phoenix type) |
Panel PC approved for maritime use. Other sizes and models can be offered. Contact the sales department for more information.
These are usually Build To Order. Contact the sales department regarding delivery time.
