Adlink DAQe-2010. 4 kanals 14 bit A/D dataopsamling, 2MHz / kanal, PCIE
21,945.00 kr
Ekskl. moms
4 channels, 14 bit PCI Express x1
Quantity
Ask a question
close
Specifications
| Data | 8 KB måledata |
|---|---|
| Digital I/O | 24 programmerbare TTL ind/udgange |
| Indgang | 4 differentielt koblede spændingsindgange med programmerbar forstærkning |
| Konverterings- hastighed | 2 MHz / kanal |
| Måleområde | ±10 V; ±5 V; ±2,5 V ±1,25 V; 0-10 V; 0-5 V; 0-1,25 V |
| Nøjagtighed | ±0,03 % af FSR |
| Opløsning | 14 bit |
| Stik | 68 polet VHDCI hunstik |
| Tæller | 2 stk. 16 bit TTL tællere |
This 4-channel A / D converter uses an inverter for each input channel, so the conversion can take place exactly simultaneously on all channels, which is often a requirement when measuring signals with high bandwidth. In addition, use of the A / D converter's full speed. The conversion of multiple A / D card installed in the same PC can be synchronized. DMA transfers are supported, as A / D converter full speed can be utilized. The differentially coupled inputs ensures the best possible noise suppression.
