I/O module with 12 digital inputs and 6 digital outputs. Web-based. Modbus / TCP / UDP

12 x Digital inputs and 6 x Digital outputs. 1 x RJ45 Ethernet. Modbus/TCP / Modbus/UDP. Pair-compound, 10 - 30VDC

Name: 12 x Digital inputs and 6 x Digital outputs. 1 x RJ45 Ethernet. Modbus/TCP / Modbus/UDP. Pair-compound, 10 - 30VDC
Brand: Danbit A/S
SKU: ETHIO12I6O-I
Price: 1858 DKK
Availability: InStock

Product number ETHIO12I6O-ICategory Via Network

1,858.00 kr

Ekskl. moms

Built-in Web server
Web HMI
Support for both Modbus TCP and Modbus UDP protocols
Communications Security
1 x RJ45 Ethernet port
Double watchdog
Operating temperature range: -25 to +75°C
I/O pair connection, the input is mirrored in the other's output
Built-in I/O
12 x Digital input: Wet / Dry, 0 - + 50VDC
All entries are 32-bit counter 500Hz
6 x digital output: Open Collector 0 - + 30VDC / 100mA
Supply voltage: 10 - 30VDC

Quantity

Physically in stock

Get Volume Offer DOWNLOADS

Ask a question

Specifications

Forsyning	10 - 30 VDC, 2 W via klemrække
Indgang	12 stk. Logisk 0: Lagt til stel Logisk 1: Åben
Netværk	10/100 Mbit m/RJ45-stik
Protokol	Modbus/TCP, TCP/IP og UDP.
Tæller	Indgange kan virke som 32 bit tæller, maks. frekvens 500 Hz
Udgange	6 stk. “open collector”: 30 V/100 mA

ETHIO12I6O-I provides full network functionality and a variety of I / O functions together with web-based Ethernet I / O monitoring and control modules, which means that the modules can be remotely controlled using Modbus TCP / UDP protocol via an Ethernet network. This ensures that ETHIO12I6O-I provides integration with HMI, SCADA, PLC and other industrial control software systems. ETHIO12I6O 6-I provides digital output channels of the sink type, and 12 digital input channels with wet contact, each of which can be used as a 32-bit counter.
